The device capable of measuring the permeability of the plug sample in steady state along with the permeability standard for calibration for two flow ranges: low 0-20 and high 0-500 cc/min by pure laboratory nitrogen gas and also a gas filtration system by applying back pressure for It maintains the flow in Darcy mode.
The high speed of the device in accurate measurement of gas permeability at several points and the direct measurement of the pressure difference of the flow passing through two faces of the rock are other capabilities of this device. The measuring range of the device is one micro Darcy to 10 Darcy and the reproducibility of the results of the device is associated with a very small error.
• Back pressure
• Data processing and recording system
• Pressure regulator
• Gas purification device
• Frame with machine table
• Ambient thermometer
• Pressure gauge, ambient pressure gauge, 2 gauge
• Core holder
• Pressure gauge difference sensor one number
• Air capsule
• Nitrogen laboratory gas capsule with 99.99% purity
• 2 gas flow meters with the ability to measure 20 cc/min and 200 cc/min
• 2 pressure sensors with a display
