A device for measuring the relative permeability of liquid gas in tank conditions

Liquid gas relative permeability measurement device is used to determine the relative permeability of gas/oil and gas/water systems in tank conditions. This device includes high pressure transfer containers, injection gas moistening system, data display and recording system such as: temperature, injection pressure, output pressure, overhead pressure, back pressure of the system, pressure difference between the two ends of the sample, and the rate of produced gas, adjustment system temperature and pressure. The efficiency of the system is up to a temperature of 150 degrees Celsius and a pressure of 10,000 pam. In the design of the heating system, all the inlet and outlet valves of the flow path are installed in such a way as to minimize the heat loss during the test.
The mentioned relative permeability system has the lowest possible dead volume in the production area. In the production part, there is a special separating device that records and measures the volume of produced liquid with high accuracy based on time. The presence of relative permeability calculator software and production data matching software are other advantages of this device
