Bending beam lifting device

The flexural measuring device of bent beams examines the change of location of bent beams and Castigliano’s theory is investigated. This device consists of three types of curved beams: ring, semi-circle and quarter-circle, as well as measuring clocks and special hooks for applying force. Measuring clocks can be easily moved and installed on the type of bent beam under test.

Category Strength of Materials Laboratory

Description

Description

• Gravitational loading mechanism
• Steel beam in three geometric shapes full circle, half circle, quarter circle
• The circular finishing beam has 3 mechanical gauges to measure displacement with an accuracy of 0.01mm
• Incomplete circular beam, each with 2 mechanical gauges measuring displacement of 0.01mm
• Carefully structured, simple and clear training
• 3 loading shelves
• Device with teaching power point and student agenda and calculation notebook
• The structure of the device has electrostatic paint
